Product Description
Peb qhov kev ua tau zoo -4 meter qhov chaw ncej radar radomeengineered rau kev sib txuas lus tseem ceeb, radar, thiab satellite daim ntawv thov, peb 4 meter qhov chaw ncej radar radome muab kev tiv thaiv tsis sib xws thiab kev ua haujlwm rau cov kav hlau txais xov rhiab heev. Lub qhov rooj ruaj khov no yog tsim los tiv thaiv cov khoom siv hluav taws xob zoo tshaj plaws los ntawm ib puag ncig hnyav tshaj plaws -xws li cua huab cua, hnyav daus, corrosive ntsev tsuag, thiab khaus UV raug - xyuas kom tsis muaj kev cuam tshuam kev lag luam thiab kev cia siab ntev -.
Cov4 meter qhov chaw ncej radar radome'slub zog tseem ceeb nyob hauv nws cov kev tsim kho siab heev. Nws nta ib tug precision -engineered moj khaum ntawm siab - lub zog, lub teeb yuag aluminium los yog galvanized steel cov tswv cuab, tsim ib tug nruj geometric qhov chaw truss qauv. Lub moj khaum no yog clad nrog ruaj, electromagnetically pob tshab panels. Raws li qhov yuav tsum tau ua thiab kev ua tau zoo, cov vaj huam sib luag no tuaj yeem hloov kho los ntawm kev sib xyaw laminates lossis cov khoom siv tshwj xeeb dielectric, optimizing teeb liab kev ncaj ncees nrog tsawg qhov nkag poob thiab superior yoj kis tus yam ntxwv.
Qhov Zoo Tshaj Plaws ntawm Peb Tsim
Exceptional structural kev ncaj ncees nrog lub optimized hwj chim - mus rau - luj piv, yooj yim installation thiab txo ntauwd load. Kev tsim kho modular tso cai rau sai sai ntawm - qhov chaw sib dhos thiab scalability rau cov kab uas loj heev. Nws configuration ua kom zoo aerodynamic kev ua tau zoo, txo cov cua cab thiab txo cov dej khov. Tsis tas li ntawd, tus tsim inherently muab kev tiv thaiv xob laim txhim khu kev qha thiab kev tswj xyuas thermal zoo.
Qhov zoo tshaj plaws rau hauv av-raws li kev sib txuas lus satellite (SATCOM), huab cua radar, huab cua ceeb toom ntxov, thiab kev tiv thaiv kev tiv thaiv, qhov 4 meter qhov chaw teeb tsa radar radome lav lub teeb liab kev ncaj ncees thiab muaj qhov system muaj. Nws yog qhov kev daws teeb meem rau cov neeg ua haujlwm uas xav tau lub sijhawm ua haujlwm siab tshaj plaws, kev saib xyuas tsawg, thiab qhov ua tau zoo ntawm electromagnetic los ntawm lawv cov cuab yeej kav hlau txais xov hauv txhua qhov kev nyab xeeb lossis chaw ua haujlwm. Peb muab tag nrho customization kom tau raws li qhov project qhov ntev, zaus bands, thiab ib puag ncig specifications.
Tshwj xeeb nta
- Modular Rapid-Deployment Design
- Advanced Aerodynamic & Anti-Icing Profile
- Integrated Lightning Protection System
- Redundant Environmental Seal & Pressure Equalization
- Cov qauv kev ncaj ncees rau ib puag ncig hnyav
- Smart Monitoring Interface (Yeem)
- Kev Pabcuam Lifecycle tag nrho
Technical Parameters
|
Qeb Parameter |
Specification |
|
Qauv & General |
|
|
Cua Load (Sustained) |
200 km / h |
|
Sab hauv |
Ntau dua lossis sib npaug li 4.6 m |
|
Tsim Lub Neej |
>15 xyoo |
|
Hluav taws xob Performance |
|
|
Kev xa tsis tau |
< 1.3 dB in V-band [37.5-42.5] GHz, Q-band [47-52.4] GHz, and Ka-band [20.2-21.2] & [30-31] GHz |
|
Passive Intermodulation (PIM) |
< -125 dBm (with two 60W carriers) in bands [37.5-42.5] GHz & [47-52.4] GHz |
|
Radome-Induced Hla-Polarization Isolation (XPD) |
Degradation <3 dB (piv txwv li, los ntawm kav hlau txais xov XPD ntawm 33 dB txog> 30 dB) |
|
Radome-Induced RF Beam Deflection |
< 2 milli-degrees |
|
Environmental Resilience |
|
|
Ua haujlwm kub |
-45℃rau +55 degree |
|
Cov av noo |
100% (condensing) |
|
Hnub Ci Flux |
Txog li 1120 W / m² |
|
Ntsev Fog (Coastal) |
33.6 g / m² / xyoo |
|
Ozone Resistance |
100 ppm |
|
Hlo Impact |
30mm txoj kab uas hla ntawm 25 m / s ntsug tshaj tawm |
|
Fungus Resistance |
Ib MIL-HDBK-454 |
|
Xuab zeb, plua plav, nag |
Rau MIL -STD-810 |
|
Qhov siab (Low Pressure) |
Mus txog 3000 m |
|
Los nag / Daus nag |
Mus txog 260 mm / h |
|
Nto & Coatings |
|
|
Hydrophobic txheej |
Dej Contact Angle> 97 degree |
|
Standard Accessories |
Access Hatch, Lightning Protection Rods, Snow Ropes, Ventilation Ports, Lifting Lugs |
|
Ntim & Shipping |
Ntoo crate lossis thav duab haum rau hiav txwv / kev thauj mus los |
Daim ntawv thov
- Satellite Ground Station Networks
- Tom ntej no -Generation 5G/6G Fixed Wireless Access (FWA) Backhaul
- Maritime & Offshore Communications
- Siab -Kev Saib Xyuas Lub Ntiaj Teb Muaj tseeb & Kev Ruaj Ntseg
- Polar & High -Qhov Chaw Tshawb Nrhiav Qhov Siab
- Critical Infrastructure & Civil Security Networks
Tom qab -Kev Pabcuam Muag
- Comprehensive Warranty Program
- Cov Kws Tshaj Lij Txhim Kho Kev Saib Xyuas & Kev Pabcuam Kev Pabcuam
- Ntiaj teb no Technical Support & 24/7 Emergency Response
- Planned Maintenance Programs (PMP)
- Ntawm -Thov Kho & Hloov Cov Cheeb Tsam
- Performance Verification & Re{0}}certification Services
- Lifecycle Upgrade & Retrofit Consulting
- Cov ntaub ntawv nthuav dav & Kev cob qhia
FAQ
1) Yuav ua li cas yog lub sij hawm nruab ib txwm rau a4 meter qhov chaw ncej radar radomentawm hom no?
Rau tus qauv, ua ntej- qauv tsim qauv, tus qauv tsim qauv tso cai rau ua tiav ntawm - qhov chaw sib dhos thiab erection los ntawm cov neeg ua haujlwm cob qhia feem ntau hauv 1-2 hnub ua haujlwm, nyob ntawm qhov loj thiab qhov chaw. Qhov kev xa tawm sai sai no yog qhov txiaj ntsig tseem ceeb tshaj li cov qauv kev tsim vaj tsev ib txwm muaj, txo cov sijhawm ua haujlwm ua haujlwm.
2) Yuav tsum muaj kev saib xyuas li cas, thiab ntau npaum li cas?
Lub 4 meter qhov chaw ncej radar radome yog tsim los rau kev saib xyuas tsawg heev. Peb pom zoo kom kuaj pom txhua xyoo thiab kev soj ntsuam ntxaws ntxaws txhua 3-5 xyoos. Cov dej num tseem ceeb suav nrog kev txheeb xyuas qhov kev sib foob, txheeb xyuas lub zog ntawm qhov tseem ceeb ntawm cov bolts, tshuaj xyuas cov txheej txheem hydrophobic, thiab xyuas kom cov vents thiab cov kav dej kom meej. Peb Qhov Kev Pabcuam Saib Xyuas Kev Npaj (PMP) muab cov sijhawm teem sijhawm thiab daim ntawv kuaj xyuas.
3) Yuav ua li cas cov4 meter qhov chaw ncej radar radomeua nyob rau hauv huab cua txias?
Lub aerodynamically optimized profile yog tsim los los daus daus thiab cuam tshuam cov dej khov. Tus qauv nws tus kheej tau ntawv pov thawj los tiv thaiv cov dej khov hnyav raws li tau teev tseg (xws li, raws li 100- xyoo cov ntaub ntawv hauv cheeb tsam). Rau kev ua haujlwm tseem ceeb, xaiv lub tshuab cua sov lossis cov dej khov tsis muaj zog-phobic coatings tuaj yeem ua ke kom txo qis kev pheej hmoo ua haujlwm cuam tshuam nrog cov dej khov ua rau ntawm qhov chaw.
4) Can lub4 meter qhov chaw ncej radar radomeraug kho kom haum rau tsis yog - tus qauv zaus lossis qhov ntau thiab tsawg?
kiag li. Thaum peb muab cov qauv qauv optimized rau ntau bands (C, X, Ku, Ka, V, Q, L), peb cov tub ntxhais engineering muaj peev xwm yog tag nrho customization. Peb tuaj yeem tsim cov radomes rau txhua txoj kab uas hla thiab txiav cov qauv tsim hluav taws xob ntawm cov vaj huam sib luag kom ua tau raws li qhov tshwj xeeb zaus, bandwidth, thiab kev poob qis sab nraum cov qauv.
5) Yuav ua li cas yog tias ib lub vaj huam sib luag puas lawm? Ua tag nrho4 meter qhov chaw ncej radar radomeyuav tsum tau ua offline?
Tsis yog. Ib qho tseem ceeb ntawm peb tus qauv tsim yog localized serviceability. Txhua tus neeg lub vaj huam sib luag tuaj yeem nkag mus tau nyab xeeb thiab hloov los ntawm sab nrauv siv cov txheej txheem tshwj xeeb, tsis tas yuav tsum muaj lub kav hlau txais xov sab hauv kom tsis txhob ua haujlwm lossis tag nrho cov qauv radome yuav tsum tau muab tshem tawm. Qhov no drastic minimizes downtime rau kho.
6) Koj ua li cas kom ntseeg tau tias qhov kev ua tau zoo RF (xws li PIM qis) tau tswj xyuas lub neej ntawm cov khoom?
Kev ua haujlwm ntev yog tsim los rau hauv. Peb siv corrosion-resistant, non-ferrous cov ntaub ntawv thiab tshwj xeeb platings rau tag nrho cov RF- tseem ceeb fasteners thiab pob qij txha. Peb qhov kev sib txuas tsim kom txo qis kev sib txuas ntawm cov hlau tsis sib xws, thiab cov txheej txheem sib dhos suav nrog kev tswj lub zog nruj thiab PIM- kuaj xyuas. Lub foob ib puag ncig tiv thaiv kev xeb sab hauv, uas yog thawj qhov ua rau ntev -PIM degradation.
Cim npe nrov: 4 meter chaw ncej radar radome manufacturers, lwm tus neeg, manufacturers, tsim, customized, kev loj hlob, satellite, advanced
